SMS Sanitary Butterfly Valve Thread End with Multi-position Handle
Features
The butterfly valve is designed for food & beverage processing, chemical products, industrial fluid applications.
Disc fully machined and polished
100% inspected
SMS sizes
|
Size |
Outside Diameter(OD) |
|
Φ19 |
19mm |
|
Φ25 |
25.4mm |
|
Φ32 |
31.8mm |
|
Φ51 |
50.8mm |
|
Φ63 |
63.5mm |
|
Φ76 |
76.2mm |
|
Φ89 |
89mm |
|
Φ102 |
101.6mm |
|
Φ108 |
108mm |
Stainless steel sanitary butterfly valves can be opened automatically through actuator or manually with handle.
The handle blocks hygienic butterfly valves in the " open " or " closed " position, certainly there are the other position available.
The actuator push piston of axial movement into 90 degree so that it controls sanitation butterfly valves.
Manual Handle Type
About manual handing, there are four different types for choosing, they are different materials with different adjusting positions.
A - Round Pull Handle with 2 positions, 3 positions, 4 positions, avaiable for all types sanitary butterfly valve
B-Square Pull Handle with 2 positions, 3 positions, 4 positions, avaiable for all types sanitary butterfly valve
C-multi-position Handle (plastic handling) with 12 positions of 15 degree each position, avaiable for all types sanitary butterfly valve
D-multi-position stainless steel handle with 12 positions of 15 degree each position, avaiable for all types sanitary butterfly valve
Package
More Information
| Payment Term | L/C, T/T, Western Union,Paypal |
| Delivery Time | 15 - 30 days after payment |
| Seaport | Shanghai Or Ningbo China |
| The 3rd Inspection | Available |
| Sample | Available for SMS Sanitary butterfly valve |
| Warranty Period | 18 months after shipments and 12 months after installed |
| Valve Test | 100% quantity tested before delivery |
| Packing | Plywood Case for SMS Sanitary butterfly valve |
| MOQ | 1 Pc for SMS Sanitary butterfly valve |
| Nameplate | According to customer for SMS Sanitary butterfly valve |
| Color | According to customer for SMS Sanitary butterfly valve |
| Shipment | By sea,By Air ,By Express,and door to door available |
| OEM/ODM Service | Available |
SMS Sanitary butterfly valve is a stainless steel butterfly valve with high precision and purity requirements for the industries of food and beverage, beer brewing, biopharmaceutical, and fine chemicals.
Stainless steel sanitary butterfly valve has a simple structure, it is mainly composed of a split body, a valve disc, a valve stem and a driving.
Compared with sanitary ball valve, sanitary butterfly valve not only have the advantages of simple structure, small size, light weight, small material consumption, small installation size etc., but also have small driving torque, simple and rapid operation, and good flow regulation, sealing characteristics etc.
When the butterfly valve is in the fully open position, the thickness of the disc is the only resistance when the medium flows through the valve body.
So the pressure drop generated by butterfly valve is small, the valve has better flow control characteristics. In the food grade industry, sanitary butterfly valve is one of the largest and most common hygienic valve.
Sanitary SMS Butterfly Valve is SMS series sanitary butterfly valves, RXVAL offer it from DN15 to DN100 in stainless steel 1.4301, 1.4404, T304, T316L etc.
Sanitary SMS butterfly valve is our strength sanitary valves , we make it by CNC machine to get high precision and high purity surface to meet the request of hygienic industries.
It is idea choice for the applications of Food, Brewery, Beverage, Dairy, Pharmaceutical etc.
