SMS Sanitary Butterfly Valve Welding End with Pull Handle

Short Description:

Size Φ19(19mm) to Φ108(108mm)
Material 304/304L and 316/316L Stainless Steel
Connection Clamp,Welding,Threaded
Pressure up to 150 PSI
Temperature up to 130℃
Seat Material EPDM, PTFE, Silicon, Viton,NBR,FPM and son on
Operation Pull Handle, Multi-position Handle
Applicable Standard SMS/DIN11850/IDF/ISO
Port Full Port
Application Food process, Milk process, Beer brewage, Bio-pharmacy

Product Detail

Product Tags

Features

● The body and disc of the Sanitary butterfly valve are built with high-precision CNC lathe processing.
● Sanitary butterfly valves are compact, lightweight, and use a simple composition with only a few components.
● Using a butterfly valve is simple and convenient;
● The disc only needs to rotate 90° to be able to open and close quickly and provide dependable fluid control characteristics.
● The Sanitary butterfly valve has two types of seals — a ballistic seal and a metal seal.
● An elastic seal valve can be embedded in the valve body or attached to the disc around.

SMS sizes

Size

Outside Diameter(OD)

Φ19

19mm

Φ25

25.4mm

Φ32

31.8mm

Φ51

50.8mm

Φ63

63.5mm

Φ76

76.2mm

Φ89

89mm

Φ102

101.6mm

Φ108

108mm

Quality Ensure

1.PMI test to verify material grade
2.Dimension controlling during fabricating and finished
3.Visual and surface 100% examination before shipment
4.Packed in carton box firstly, then in wooden case
5.Third party inspection available.

Package Details

Bubble pack for each valve.
Outside packing are carton or plywood cases.
Or as per the request of customers.

SMS Sanitary Butterfly Valve Clamp End (6)

Manual Handle Type

About manual handing, there are four different types for choosing, they are different materials with different adjusting positions.
SMS Sanitary Butterfly Valve Welding End with Pull Handle (1)

A - Round Pull Handle with 2 positions, 3 positions, 4 positions, avaiable for all types sanitary butterfly valve
B-Square Pull Handle with 2 positions, 3 positions, 4 positions, avaiable for all types sanitary butterfly valve
C-multi-position Handle (plastic handling) with 12 positions of 15 degree each position, avaiable for all types sanitary butterfly valve
D-multi-position stainless steel handle with 12 positions of 15 degree each position, avaiable for all types sanitary butterfly valve

Remember, sanitary valves must meet special sterile requirements, especially for the valve body and sealing components. The sealing surface of the valve seat must be non-toxic. For example, the material for hard sealing and soft sealing can be stainless steel and rubber. the most common types of sanitary valves are sanitary butterfly valves and sanitary ball valves. Other common sanitary valves include sanitary check valves, sanitary solenoid valves, and sanitary diaphragm valves.

RXVAL offers comprehensive range of valve and valve automation solutions that meet all your needs in a reliable and cost effective manner. A long and proven track record in catering to various industrial sectors such as Chemical, Pharma, Oil & Gas, Power and Fertilizers through its solutions is the key strength of RXVAL.
