API 602 Forged Steel Globe Valve NPT/BW/SW
Features
●Outside Screw and Yoke (OS&Y)
●Bolted Bonnet with Spiral-wound Gasket
●Integral Backseat
●Full Port option available
Design of the Forged Steel Globe Valve
Material of the Forged Steel Globe Valve
|
No. |
Part |
Carbon Steel |
Stainless Steel |
Alloy Steel |
|
1 |
Body |
A105 |
A182 F304 |
A182 F11 |
|
2 |
Disc |
A182 F6a |
A182 F304 |
A182 F6a |
|
3 |
Stem |
A276-410 |
A276-304 |
A276-410 |
|
4 |
Gasket |
Graphite+304 |
||
|
5 |
Sealing |
Graphite |
||
|
6 |
Yoke |
A216 WCB |
A351 CF8 |
A216 WCB |
|
7 |
Bonnet |
A105 |
A182 F304 |
A182 F11 |
|
8 |
Gland |
A216 WCB |
A351 CF8 |
A216 WCB |
|
9 |
Bolt |
A193 B7 |
A193 B8 |
A193 B16 |
|
10 |
Packing |
Graphite |
||
|
11 |
Bushing |
A276 -410 |
A276 -304 |
A276-410 |
|
12 |
Gland |
A216 WCB |
A351 CF8 |
A216 WCB |
|
13 |
Eye Bolt |
A193 B7 |
A193 B8 |
A193 B7 |
|
14 |
Stem Nut |
A276 410 |
||
|
15 |
Hand-wheel |
A197 |
||
Advantages
1.Made of Forging stell for the body of Forged Steel Globe Valve
2.Factory supplied with competitive price
3.All the test reports offered before shipment for approved
4.100% testing before shipment and ensure 0 leakage for floating ball valve
Other Information
| Payment Term | L/C, T/T, Western Union,Paypal |
| Delivery Time | 15 - 30 days after payment |
| Seaport | Shanghai Or Ningbo China |
| The 3rd Inspection | Available |
| Sample | Available for Forged Steel Globe Valve |
| Warranty Period | 18 months after shipments and 12 months after installed |
| Valve Test | 100% quantity tested before delivery |
| Packing | Plywood Case for Forged Steel Globe Valve |
| MOQ | 1 Pc for Forged Steel Globe Valve |
| Nameplate | According to customer for Forged Steel Globe Valve |
| Color | According to customer for Forged Steel Globe Valve |
| Shipment | By sea,By Air ,By Express,and door to door available |
| OEM/ODM Service | Available |
API Trim Chart For Forged Steel Globe Valve
|
TRIM |
MATERIAL |
SEAT |
DISK |
BACKSEAT |
STEM |
NOTES |
|
1 |
410 | 410 | 410 | 410 | 410 | |
|
2 |
304 | 304 | 304 | 304 | 304 | |
|
3 |
F310 | 310 | 310 | 310 | 310 | |
|
4 |
Hard 410 | Hard 410 | Hard 410 | 410 | 410 | Seats 750BHN Min |
|
5 |
Hard faced | Stellite | Stellite | 410 | 410 | |
|
5A |
Hard faced | Ni-Cr | Ni-Cr | 410 | 410 | |
|
6 |
410 and Cu-Ni | Cu-Ni | 410 | 410 | 410 | |
|
7 |
410 and Hard 410 | Hard 410 | Hard 410 | 410 | 410 | Seats 750BHN Min |
|
8 |
410 and Hard Faced | Stellite | 410 | 410 | 410 | |
|
8A |
410 and Hard Faced | Ni-Cr | 410 | 410 | 410 | |
|
9 |
Monel | Monel | Monel | Monel | Monel | |
|
10 |
316 | 316 | 316 | 316 | 316 | |
|
11 |
Monel and Hard Faced | Stellite | Monel | Monel | Monel | |
|
12 |
316 and Hard Faced | Stellite | 316 | 316 | 316 | |
|
13 |
Alloy 20 | Alloy 20 | Alloy 20 | Alloy 20 | Alloy 20 | |
|
14 |
Alloy 20 and Hard Faced | Stellite | Alloy 20 | Alloy 20 | Alloy 20 | |
|
15 |
304 and Hard Faced | Stellite | Stellite | 304 | 304 | |
|
16 |
316 and Hard Faced | Stellite | Stellite | 316 | 316 | |
|
17 |
347 and Hard Faced | Stellite | Stellite | 347 | 347 | |
|
18 |
Alloy 20 and Hard Faced | Stellite | Stellite |
